- Automotive
- Personal/Portable Navigation (PDA, Pocket PC etc.)
- Sports and Recreation
- Geographic Surveying
|
|
| |
|
| |
| |
 |
\
| |
| General |
| GPS Chip |
NEMERIXultra low power GPS module |
| C/A Code |
1.023MHz chip rate |
| Channels |
16 channels all in view |
| Internal Back-up battery |
3.0V, 1.4mAh, Lithium |
| Tracking Sensitivity |
| -152dBm |
| Acquisition Rate |
| Cold Start |
60 sec, 50% |
| Warm Start |
38 sec, 50% |
| Hot Start |
12 sec, 50% |
| Reacquisition |
1 sec, average |
| Update Rate |
1 Hz |
| Accuracy |
| Position |
3m CEP (50%), 7m (90%) |
| Velocity |
0.1m/sec, without SA |
| Time |
±100ns synchronized to GPS time |
| Power |
| DC 3.6 ~ 5.5V, 38mA typ. |
| Environmental |
| Operating Temperature |
- 40°C to + 85°C |
| Storage Temperature |
- 55°C to + 85°C |
| Relative Humidity |
5% to 90% non-condensing |
| Dynamic Conditions |
| Altitude |
10,000m Max |
| Velocity |
Hor.300km/hour;Ver.36km/hour Max |
| Acceleration |
2g Max |
| Interface |
| USB |
Optional |
| RS232 |
Optional |
| PDA |
Optional |
| GPS Protocol |
| NMEA-0183(V3.0)-GGA(1),GSA(3), GSV(3),RMC(1),VTG(1) * |
| Dimensions |
| W x D x H (mm) |
53 x 60 x 26 |
| W x D x H (inch) |
2 x 2.3 x 1 |
| Weight |
60g |
| Data Cable (Length) |
2m (6 pin) |
| Optional Cable |
| RS232 Cable (R101) |
20cm with PS2 jack |
| USB cable (U101) |
50cm |
| PDA cable (P101) |
Compaq ,HP |
|
|
|
|
