General

Accuracy (none DGPS)

GPS Chip

MTK GPS Module

Position

Frequency

L1, 1575.42MHz

Without aid: 3.0m 2D-RMS
< 3m CEP(50%) without SA(horizontal)
DGPS (WAAS, EGNOS, MSAS): 2.5m

C/A Code

1.023MHz chip rate

Velocity

Without aid: 0.1m /s, DGPS(WAAS, EGNOS, MSAS): 0.05m /s

Channels

51-CH performance tracking

Time

50 ns RMS

Antenna (Intemal)

Built-in patch antenna with LNA

Datum

WGS-84

Sensitivity

Dynamic Conditions

Tracking -158 dBm

Altitude

< 18,000m

Acquisition Rate

Velocity

< 515m /sec

Cold Start

36 sec, average

Acceleration

< 4g

Warm Start

33 sec, average

Update

1Hz as default (1~5Hz adjustable)

Hot Start

1 sec, average

Interface

Reacquisition

< 1 sec.

Bluetooth

V1.2 compliant (SPP profile)

Power

Class 2 (15 meters in open space)

Built-in rechargeable Li-ion battery

Frequency: 2.4~2.4835 GHz

Power Charge

Mini USB

Power On/Off

Slide switch

Operation Time

32hrs, after fully charged, in continuous

GPS Protocol

Charging time

3hrs. (Typical)

NMEA-0183 (V3.01) - GGA, GSA,GSV, RMC(default), Baud rate 115200 bps, Data bit : 8, stop bit : 1(Default)

Environmental

Operating Temperature

- 10 ? to + 60 ?

Storage Temperature

- 20 ? to + 60 ?

Charging

0 ? to + 45 ?

Device Size

Accessories

72.2 (L) X 46.5 (W) X 20 (H) mm

110~220V Power Adapter

LED function

Car Charger

Bluetooth connection, Navigation Status, and Battery/charger status

Rechargeable Battery

Certification

CE/FCC/RoHS
